| DC Voltage | 12V or 24V or 48V or 110V |
| Voltage Range | 10-15VDC or 21-30VDC or 42-60VDC or 90-135VDC |
| NO Load Current Draw | <0.5A |
| Efficiency | >90% |
| DC Connector | Cables With Clips or Car Adaptor |
| AC Voltage | 100/110/120VAC or 220/230/240VAC |
| Continuous Power | 300W |
| Surge Power | 600W |
| Waveform | Pure Sine Wave |
| Frequency | 50HZ or 60HZ |
| AC Regulation | 3% |
| Low Voltage Alarm | 10DC±0.5V or 20.5DC±1V or 44VDC±1V or 92VDC±1V |
| Low Voltage Shut Down | 9.5DC±0.5V or 19.5DC±1V or 42VDC±1V or 90VDC±1V |
| Over Load | Shut Off Output |
| Over Voltage Shut Down | 15.5V or 30.5V or 61.2V or 135V |
| Over Thermal | Shut Off Output Automatically |
| Fuses | Short Circuit |
| Working Temperature | Between -10centi and +50centi |
| Working Humidity | 20%~90%RH non-condensing |
| Storage Temperature | Between -30centi and +70centi |
| Start | Soft Start |
| Cooling Ways | Cooling Fan |
| Total Harmonic Distortion THD | <5% |
| Machine Size(mm) | 240 * 175 * 95 |
| Packing Size(mm) | 360 * 230 * 160 |
| Net Weight(kgs) | 2.38 |
| Gross Weight(kgs) | 3.1 |
| Packing Type | Carton Packing |
1. Use advanced double CPU single chip computer intelligent controle technology. It is a higly reliable inverter with very low failure rate.
2. Pure sine wave output, with strong overload capability and wide application.
3. has complete protection functions(over-loaded protection, interior over heated protection, output short circuit protection, input over voltage protection ect). It can increase the reliability of the product.
4. Small size and light weight. The interior part adopts CPU centralized controlling, surface mounting technology, which make the size small and weight light.
5. Cooling fan intelligent control. Adopts CPU controlled cooling fan, which expand the fan’s use durability, save power energy and improve the efficiency
6. Working noise is low and the efficiency is high
7. Earth Connection for Both Inverter and PCB,best Protection all around
8. all BIG MOSFET,strong driving capacity
9. Thick PCB of 2.00mm,
10. SMT Serface Mount Technology
11. No Noise for TV or Stereo Sound
12. automatic chip mounter
13. Durable quality with 10 years usage , our pure sine wave inverters are approved by EMC testing in Australia and CE certified , 18 monthes warranty.
We YUEQING RELIABLE ELECTRIC CO.,LTD is a leading manufacturer for PURE SINE WAVE INVERTER from 150W to 8000W in China for more than 7 years . As the factory , we will support you most in quality , price and service .
FAQ
Q 1. what's the payment term?
A. We accept TT, PayPal , Western Uninon
Q 2. how's the delivery time ?
A. Sample will be sent in 3days, big order according to the quantity , 2 weeks at most
Q 3. tell me the standard of package?
A. For the small capacity, it use carton, but for big capacity, we should use strong wooden case for protection.
Q 4. what kind of material of transformer?
A. We use 100% copper
Q 5.Could you offer Form A or C/O ?
A. Really no problem. We can prepare relative documents to forgin affairs office or other office to apply for this certificate.
Q 6.Would you accept to use our logo ?
A.If you have good quantity,absolutely no problem to do OEM.
Q 8.Where is your market?
A. We have been doing Europe, Russia , America ,Brazil ,Australia market for about 8 years , reliable quality make our business last long
Q 9.Does the inverter connect with solar system ?
A.Yes. we have both off grid and on grid pure sine wave inverter
Q10. what kind of certificate you have ?
A. Our company already achieve CE , EMC certification .
